3470mm Dimensions 3 Tons 5 Tons 1SUZU KV100 Refrigerated Truck 4.2m Van Box Refrigerator Trucks

Product Categories
Hubei Huate Special Equipment Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

3470mm Dimensions 3 Tons 5 Tons 1SUZU KV100 Refrigerated Truck 4.2m Van Box Refrigerator Trucks

Place of Origin : Hubei, China, /

Brand Name : HUATE

Price : $28,000/units 1-9 units

Transmission Type : Automatic

Condition : New

Horsepower : < 150hp

Emission Standard : Euro 4

Fuel Type : Gasoline

Dimensions (L x W x H) (mm) : 5995*2070.2160.2260* 3170,3270,337 0,3470

Box Dimensions (L x W x H) (mm) : /

Temperature Range : /

Gross Vehicle Weight : ≤5T

After-sales Service Provided : Onsite Installation, Video technical support, Online support

Maximum Torque(Nm) : ≤500Nm

Capacity (Load) : 1-10T

Engine Capacity : < 4L

Color : Custom's Requirement

MOQ : 1

Packaging Details : Wooden box

Delivery Time : 7-30 days

Payment Terms : T/T

Supply Ability : Meet large-scale orders

Contact Now

Products Description
3470mm Dimensions 3 Tons 5 Tons 1SUZU KV100 Refrigerated Truck 4.2m Van Box Refrigerator Trucks
3470mm Dimensions 3 Tons 5 Tons 1SUZU KV100 Refrigerated Truck 4.2m Van Box Refrigerator Trucks
3470mm Dimensions 3 Tons 5 Tons 1SUZU KV100 Refrigerated Truck 4.2m Van Box Refrigerator Trucks
3470mm Dimensions 3 Tons 5 Tons 1SUZU KV100 Refrigerated Truck 4.2m Van Box Refrigerator Trucks
3470mm Dimensions 3 Tons 5 Tons 1SUZU KV100 Refrigerated Truck 4.2m Van Box Refrigerator Trucks
3470mm Dimensions 3 Tons 5 Tons 1SUZU KV100 Refrigerated Truck 4.2m Van Box Refrigerator Trucks
3470mm Dimensions 3 Tons 5 Tons 1SUZU KV100 Refrigerated Truck 4.2m Van Box Refrigerator Trucks
Product Paramenters
Vehicle technical parameters
Product na me
Model 5043XLCW6 refrigerate d truck
Product Model
HTT5043XLCW6
Total mass (Kg)
4495
Production add ress
Suizhou City, Hubei Province
Rated load weight (K g)

1100116 5
Overall dimens ions (mm)
5995 x 2060,2160,2260 x 3030,3130, 3230
Mass of pr eparation (Kg)

3200

Axle Load

1750/2745
Number of people in the cab (p ersons)

Two-thirds of the

Number of shaf ts


2
Approach A
ngle/depar
ture Angle (.)

19/15, 22/15
Front overhang
/rear overhang (mm)

1110/1525112 0/1510
Wheelbase
3365336 0
Maximum speed (Km/h)
105
Chassis technical parameters
Chassis mo del number
QL1043BUHAY Class II
Chassis brand
Truck chassis
Number of shafts
2
Number of tire s
6
Tire Speci fications
7.00R16LT 8PR
Number of leaf sprin g pieces

6/6 + 6, 8 / + 5, 3/3 + 2, 2/3 + 2
Front whee l base (m m)

1640169, 0168, 5
Rear wheel bas e (mm)

1655152 5
Types of f uel
Diesel
Anti-lock brak ing system
There are
Chassis wh eelbase

3365336 0

Fuel consumption

11.41, 11.45
Emission Standards

GB17691-2018 Country VI
Engine model
Displacement (ml)
Power (Kw)
4KH1CN6HB 4KH1CN6LB
2999
2999
97
88
Company Profile
Hubei Huate Special Equipment Co., Ltd. is a manufacturer integrating the independent R&D and manufacturing and sales and import & export trading of special truck and truck accessories. It is a “ national high-tech “ enterprise and “ SRDI” enterprise. Our company was founded in February 2009 , located in Suizhou Hubei province which is the hometown of Yan Emperor and ancient music of chimes, and it is the capital of special trucks in China. Huate main products: dangerous goods tank truck series, tank container series, chemical storage tank series, dangerous goods van series, refrigerated truck series, testing vehicle series, emergency rescue vehicle series, engineering vehicle series ,sanitation vehicle series, special vehicle parts series, used truck trading and other subdivision products. We have professional technical team, strong and experienced management team, efficient domestic and overseas sales team . Huate products not only lead the domestic advanced level, but also towards the international market, forming a diversified and serialized product pattern. Huate is driven by innovation , market-oriented and brand-led . It constantly improve product quality and management level, our company has fully passed the GB/T19001-2016 idt ISO9001:2015 quality system certificate and GB/T24001-2016 idt ISO14001:2015 environmental system certificate and GB/T45001-2020 idt ISO45001:2018 occupation health safety system certificate .Our products has passed international 3C compulsory certificate and tank container CCS certificate , with a number of invention patents . We have participated in the drafting of various national standards and industry standards. The company adheres to the business philosophy of "Create industry quality products. Strive to be an industry pioneer" , based on the design and manufacturing of intelligent and digital core components, we provide clients with intelligent solutions. With its differentiation and cost-effective advantages, we provide users with superior and mutually beneficial and win-win cooperation platform. Currently our products have been exported to Africa Middle East Southeast Asia America Europe more than 30 countries , well received by domestic and foreign users with favorable comments .
3470mm Dimensions 3 Tons 5 Tons 1SUZU KV100 Refrigerated Truck 4.2m Van Box Refrigerator Trucks
Manufacturing Technique
3470mm Dimensions 3 Tons 5 Tons 1SUZU KV100 Refrigerated Truck 4.2m Van Box Refrigerator Trucks
3470mm Dimensions 3 Tons 5 Tons 1SUZU KV100 Refrigerated Truck 4.2m Van Box Refrigerator Trucks
Certifications
3470mm Dimensions 3 Tons 5 Tons 1SUZU KV100 Refrigerated Truck 4.2m Van Box Refrigerator Trucks
Customer Photos
3470mm Dimensions 3 Tons 5 Tons 1SUZU KV100 Refrigerated Truck 4.2m Van Box Refrigerator Trucks
Project Show
3470mm Dimensions 3 Tons 5 Tons 1SUZU KV100 Refrigerated Truck 4.2m Van Box Refrigerator Trucks
Product packaging
3470mm Dimensions 3 Tons 5 Tons 1SUZU KV100 Refrigerated Truck 4.2m Van Box Refrigerator Trucks

FAQ
Q1. Payment term.
T/T ,30% as despite ,and 70% before delivery from factory.
L/C, L/C price is higher than T/T price
We will show you photos and video of the finished truck before you pay the balance.

Q2. Terms of delivery
EXW, FOB, CFR, CIF, DAF ,FCA ,DDU.DAP etc .
We mainly do FOB,CIF,DAF

Q3. Delivery time
Generally, it will take 10 to 20 days after receiving your advance payment. The specific delivery time depends on the items and
the quantity of your order.
(if you need the right hand drive chassis ,delivery time is longer than Left hand drive truck,Detailed clauses are subject to
contract .)

Q4. Quality and warranty
We have Rich experience workers and engineer to control quality before and on production , we strictly follo STATE special trucks
technical specification and safety production specification . we 100% test trucks before delivery.
Our Warranty :12 months
We will provide the spare parts for free in one year.

Q5. How to trust us ?
Our company pass BV factory audit,And you also can arrange a third party inspect our factory.
We have been in this line for over 15 years, dealing with all kinds of trucks.

Q6.Visit our factory
Our factory are in suizhou city,hubei province, china.
You can take train or plane to arrive wuhan citry(wuhan city is the capital of hubei province,near our factory) .and our driver
will pick up you at wuhan railway station or wuhan tianhe airport.
And if need the invitation letter ,pls send your private information and company information to me.
